Product Description

• Master controller  + 2 PLC + IMD + LED set for dual gun
• Electrical PropertiesInput Supply 12 V DC @ 2 A Power 24 WBattery Backup 12 V rechargeable battery supported with chargingInterfacesNetwork Connection Ethernet, Wi-Fi 802.11 b/g/n and GSM (LTE, 4G Fallback to 2G), BLE Vehicle CommunicationBasic Signaling (BS) and High-Level Signaling (HLC) Power Module Interface Controller area network (CAN) HMI Communication Protocol TTL or RS-232 AC and DC Energy Meter Communication RS-485 Any Sensor Interface I2C or Digital Input Gun Temperature Measurement Input 4 Nos. RTD, PT1000 to Monitor Gun Temperature & Prevent Gun overheating LED 1 No. LED Connector supporting 3 different Neo Pixel LED blocks to Display individual Gun status and Charger Status Insulation Monitoring Device RS-485 Load Balancing Configurable Dynamic load balancing (based on EV power demand)
• Digital Payment Support On-Screen QR Code-Based UPI Support, POS Machine Integration
• Standard Support DIN 70121, ISO 15118-2, ISO 15118-20 Plug & Charge (PnC), Vehicle to grid (V2G), IEC 61851 Environment
• Operating Temperature Humidity 5 to 95% -20°C to +70°COther Features Storage MicroSD Card Support; Storage Expandable up to 32 GBFirmware Upgrade Firmware Over-the-Air (FOTA) Supply
