| Frame Material | Aluminium |
| Screen Material | Fiberglass |
| Operating Mode | Manual |
| Display Size | 15.6″, IPS ultra-thin LCD |
| Front Display Resolution | 1920 × 1080 (Full HD) |
| Aspect Ratio | 16:9 |
| Screen Tilt | ≤15° after lifting |
| Brightness | 300 cd/m² |
| Contrast Ratio | 600:1 |
| Visual Angle | 45°/45°/20°/40° (typical) |
| Panel Material | Ultra-thin 3mm anodized Aluminum, width 70mm |
| Appearance/Colo ur | Black / Silver anodized finish |
| Panel Buttons | Up (screen tilted forward), stop, down (screen restoring to vertical state), signal switching. |
| Lift Control Modes | Manual Control, RS232/485 |
| Lifting Mechanism | Linear guides + chain drive, AC geared motor driven |
| Video Input | HDMI × 2 |
| USB Port | 1x USB-A |
| Control Interfaces | RJ45 ×2 (RS-485/RS-232) |
| Power Supply | 2x DC12V power input/output |
| Safety Functions | Anti-pinch and Anti- obstacle detection |
| Max Power Consumption | 60W/96W |
| Operating Temperature | –10°C to +45°C, RH ≤80% |
| Installation Method | Embedded |
| Net weight | 9kg |
| Product Dimensions (W x D x H) |
